2 x 6 W 2 x 4" MDF AB Wall surface mounted speakers

581251

The AB wall-mounted speaker WA-AB 06-165/T is constructed with two chassis and transformers independent of each other and allows cost-effective supply through two separate (A/B) lines. In case one line fails, the area will continue sonicated through the redundancy of speakers. With any installation position, both the A and also the B line are present, thus avoiding a failure situation. The loudspeaker is equipped appropriately for the standard with 2 integrated ceramic terminals and 2 thermo fuses.
Additional Information:
Optionally can be used for the use of impact-resistant or ceiling mounting of Article 581251.10.
Loading capacity6 W
Colorwhite, similar to RAL 9010
Weight kg approx. 2.1 kg
Channel separation> 75 dB
Harmonic distortion at nominal level@ 1 kHz
Dispersion angle150°
SPL 1 W / 1 m97.8 dB
SPL Pmax / 1 m112.8 dB
Transformer power taps6 / 3 / 1,5 W
Transmission range97 ... 20000 Hz
DimensionsW: 252 mm H: 192 mm D: 82 mm
